ATC CNC Router

Customized CE safety barriber atc cnc router center with boring head ST-2132 st-1352

  • Model:ST-2132
  • Category : ATC CNC Router
  • Working area: 2100*3200*200mm
  • Standard price: 30000
  • Customized: Negoation
  • Payment Terms: T/T(Telegrahic Transfer), Master card, Visa, Paypal, West Union
  • Send Email WhatsApp WhatsApp

Customized CE safety barriber atc cnc router center with boring head ST-2132 st-1352

st-2132

suntec drawing

suntec heavy structure table

heavy dusty structure table with steel plate 10mm for longtime usage vacuum cups

some other factories using double pvc layers , Thermal expansion and contraction,pvc can deform ,then impact precision . but steel plate table just solve this problem . suntec cnc can offer professional suggestions according our nearly 20 years experience .

suntec sanding blast table

sanding plast structure for well painting

suntec control box

neat control box with schneider parts

suntec voltage screen

voltage transformer show working voltage to make sure safety working enviroment

customized door cylinder position

inside  position cylinder for door side milling routing to make door at same level to make high precisision hole hinge

suntec air plug

air plug easy to move controlbox

suntec dust hose

Dust collector hose to make clean

suntec drag chain

clean and neat electrical line high anti-temperrature antioil

suntec senstive limit

Delta limit hard limit no broken and high sentive when working

airtac

Taiwan aitac for enough air working

dust cover

dust protecor for protec square guide working clean enviroment

electrical parts

Electrical valve easy to control vacuum zone

NC controller

13 inch control screen can support chinese english spainish korean language etc .

gantry

Double exit motor for side driling routing miling door hinger hole

suntec loading container

one 40HQ can load three sets customized cnc machine ST-2138 ST-1332 ST-1352 .

one set machine weight 6000kgs . need four chuck to load

Model

ST-2138

      ST-1352

ST-1332

Travelling size

2100*3800*500mm

1300*5200*300mm

1300*3200*300

Max Working size

4600*2300*1800mm

2200*6500*1800mm

2200*5000*1800mm

Working zone

15/7/7 working zone according your working board size

Transmission

X/Y rack and pinion drive, Z ball screw drive


Table structure

 Heavy structure table with steel plate

Spindle power

9 KW/Air Cooling/ISO30

0r 11 KW/Air Cooling/HSK-F63

Driving system

850 Servo Motor/Yaskawa



Controller

OSAI CONTROLLER

NC controller

Max Spindle speed

24000r/min

Max Travelling speed

80m/min

Working speed

20m/min

Reposition Accuracy

+/- 0.025mm

Tool magazine

Linear atc 12

Voltage

AC400/3PH/50HZ

Boring head

9V3H1S/FAM /Italy

Optional boring Unit

9V6H1S/ 7V4H/ 12V8H2S

10V4H2S/ 7V4H/ 12V8H2S

9V3H1S

Net weight

5600KGS

  5600KGS

5600KGS
